Versa Lift Truss Leg Kit – Model 24

Versa Lift Truss Leg Kit for the Model 24: Install Your Versa Lift Between Roof Trusses

Many newer homes have attics framed with pre-built roof trusses on 24" centers. The Versa Lift Model 24's standard housing legs won't normally fit between them, and trusses can never be cut or modified because every member carries load. The Truss Leg Kit solves that. Its specially designed legs fit between trusses on 24" centers and bolt to the lift housing and mounting rails in place of the standard legs, so you can install a Versa Lift Model 24 in a truss attic without touching the trusses.

→ Fits the Versa Lift Model 24 only. Not compatible with the Model 32.

Features:

• Fits Between Roof Trusses: Legs are designed to fit between trusses on 24" centers, so no truss member has to be cut.
• Replaces the Standard Legs: Use the truss legs in place of the four standard housing legs that come with the lift.
• Uses the Lift's Own Mounting Rails: The standard mounting rails rest across the truss joists to carry the lift's weight. The truss legs bolt to them.
• All Special Hardware Included: Includes the shorter ¾" bolts the truss legs require. The remaining hardware comes with your Versa Lift.
• Order With Your Lift or Add Later: Add it to a new Versa Lift Model 24 order, or order it separately before you install.
• 30-Day Returns: See the Returns section for details.

What's Included:

• Left truss housing legs (2)
• Right truss housing legs (2)
• ¼-20 x ¾" hex bolts with washers (16)
• Truss Leg Kit Installation Guide Supplement

Specifications

General

• Model: TL-24
• Manufacturer: Byers Products Group (Versa Lift)
• Fits: Versa Lift Model 24 (all control types and height ranges)
• Truss Spacing: 24" on center

Installation requirements

• Lift Opening: 22½" x 46½", located between trusses on 24" centers with no truss member cut
• Truss Clearance: At least 2" between each end of the lift opening and any vertical truss member, and more for diagonal members, so the mounting rails can rest on the truss joists
• Attic Decking: Install decking around the lift opening before installing the lift head
• Crew: 2 people if there's room to maneuver the assembled lift head; 3 people for tight truss attics

Shipping

• 1 carton
• 17 lbs

Documents

• Versa Lift Truss Leg Kit Installation Guide Supplement
